جهاز قياس الأطوال/الملامح

VICI MTL X10

CONTROLS
.. electronic controls

ELECTRICAL SPECIFICATIONS
.. mains voltage: 240 V
.. mains frequency: 50 Hz

Itedpfexwt Adex Ad Asp
DIMENSIONS / WEIGHTS
.. space requirements -left/right-: 560 mm
.. space requirements -front/back-: 660 mm
.. total height: 860 mm
.. total weight approx.: 100 kg


Optical measuring machine for testing diameter, shape, roundness, angle, cylindricity, bending radius, and length.

Measuring range: Ø 8 x 100 mm
Max. workpiece dimensions: Ø 90 x 260 mm
Max. workpiece weight: 3 kg
Repeatability (diameter) at 20°C: 0.4 µm
Repeatability (length) at 20°C: 3 µm
Max. travel speed (vertical): 20 mm/s
Max. rotation speed: 180 °/s
