تراوب TNX 65/42

TRAUB TNX 65/42

This 11s TRAUB TNX 65/42 was manufactured in 2012. It features a maximum turning diameter of 175 mm and a turning length of 650 mm. The machine is equipped with a powerful main spindle speed of up to 5,000 rpm and a counter spindle speed of up to 7,000 rpm. If you are looking to get high-quality turning and milling capabilities, consider the TRAUB TNX 65/42 turn-mill centre we have for sale. Contact us for further details.

• Working hours: 26,946 h
• Max. turning diameter: 175 mm
• Max. turning length: 650 mm
• Main spindle bar capacity / bore: 65 mm
• Max. spindle torque: 275 Nm
• Counter spindle speed: up to 7,000 rpm
• Counter spindle bar capacity: 42 mm
• Tool turrets: 3 × 10 positions
• Rapid traverse X-axis: 30 m/min
• Rapid traverse Z-axis: 40 m/min
Ijdpfx Asz Dk Rijkajbb
• Rated power: 83 kW
• Connected load: 68 kVA
• Power supply: 400 V, 3~, N, PE, 50 Hz
• Rated current: 134 A

Technical Specification
Counter Spindle Yes
Driven Tools Yes
