Soraluce TA-35

Top-equipped bed type milling machine from premium manufacturer SORALUCE.

Machine hours:
Program ON: 2754 h
Spindle ON: 1716 h

Equipment features:

Control: Heidenhain TMC640 with HR510 handwheel

Table size: 3700 x 1000 mm / max. table load: 9250 kg / prepared for 4th axis
Crjdpfjxbhy Sex Ahxsh

HEIDENHAIN main spindle motor with 611 Nm
Increased main spindle drive torque by using a ZF gearbox.
A drive power of 24 kW and torque of 611 Nm are available. Hybrid bearings in the milling ram.

Automatically indexing milling head in diagonal design / 2 levels, 90° / 45°
Stepless positioning with 5,000 rpm, air cooling / oil mist lubrication.
Tool clamping force 20,000 N / including torque support for use of angle heads.
30 kW / 503 Nm – HEIDENHAIN inline motor

Prepared for DAS system by Soraluce
AKZ, high-pressure coolant (IKZ) with 40 bar frequency control, internal air

Accura Heads head compensation / Adaptive control feed regulation / Dynamic head compensation
Wireless probe M&H 20.41 Multi

Double chip conveyor in hinged belt design
Clamping devices
