آلة الغمر بالقالب EDM

Sodick AD 55 L

General Data
Measurements width 2435 mm
Measurements depth 2335 mm
Measurements height 2635 mm
Machine weight 4020 kg

Movement
X-Axis Movement 600 mm
Y-Axis Movement 400 mm
Z-Axis Movement 400 mm

Workpiece
Workpiece weight 1000 kg
Godpfsxnr Ndex Abxsuh

Media
Air pressure 0.65 MPa

Additional Equipment
Features: 10-year warranty on positioning accuracy, LN Professional, Cooling unit for linear motor, Glass scales (X, Y, Z axes), Remote control, USB port, Shuttle ATC, C-axis (SEC-10), SGF generator unit, 15" TFT touchscreen, Dielectric cooling unit, Automatic voltage stabilizer, Paper filters (2), Fire extinguisher, Mouse, LAN port, Work lighting

This Sodick AD 55 L die-sinking EDM machine was manufactured in 2016. It features a work tank with internal dimensions of 1200 x 800 x 500 mm and a capacity of 470 liters, supporting a maximum workpiece weight of 1000 kg. Equipped with a cooling unit for the linear motor, a C-axis, and a SGF generator unit, it offers robust performance for precision applications. Contact us for more information about this machine.

Application Types
EDM
