مركز بالقطع - عمودي

MORI SEIKI DuraVertical 5080 -038

x-travel 800 mm
y-travel 530 mm
z-travel 510 mm
Control MSC 504 Mori Seiki
turning speeds max. 10.000 min/-1
power capacity - main spindel 15 / 11 kW
Hsdpfx Aex R Emwei Sjnl
tool taper SK 40
spindle bearing diameter 70 mm
distance spindle /table 150 - 660 mm
table surface area 1.100 x 600 mm
max. table load 800 kg
T-slots 6x 18 mm
table height over floor 900 mm
number of toolpositions 30 pos.
tool taper SK 40
max. tool diameter 80 mm
max. tool-dia with free toolbox 125 mm
max. tool length 300 mm
max. tool weight 8,0 kg
change-time tool to tool 1,3 sec
change-time chip to chip 4,1 - max. 9,2 sec
rapid traverse ( X / Y / Z ) 36 / 36 / 20 m/min
feed speeds max. 6.000 mm/min
Tipp feed 1 - 5.000 mm/min
total power requirement 27 kVA
weight of the machine ca. 6,1 t
dimensions of the machine ca. 3,5 x 3,0 x 2,8 m
CNC - Machiningcenter Vertical
MORI SEIKI - DuraVertical 5080 -038
