مازاك QTN-200M

Mazak QTN-200M

This 4-axis Mazak QTN-200M was manufactured in 2004. It features a maximum turning diameter of 380 mm and a maximum swing diameter of 675 mm. The machine is equipped with a powerful main spindle that reaches speeds of up to 5,000 rpm and a robust tool turret with 12 positions. If you are looking to get high-quality turning capabilities, consider the Mazak QTN-200M machine we have for sale. Contact us for further details.

- Work Area:- Max. Swing Diameter: 675 mm- Max. Swing Diameter over Cross Slide: 276 mm- Max. Turning Diameter: 380 mm- Max. Bar Work Capacity: 65 mm- Main Spindle:- Main Drive Power (30 min rating / 100% continuous): 26 kW / 22 kW (Integrated Spindle Motor)- Max. Torque: 350 Nm- Spindle Nose: A2-6"- Spindle Bore: 76 mm- Chuck Diameter: 210 mm- Second Spindle (Sub-spindle):- Drive Power (30 min rating / 100% continuous): 10 kW / 7.5 kW- Max. Torque: 75 Nm- Speed Range: 35 - 6,000 rpm- Indexing: 0.001°- Chuck Diameter: 169 mm- Tool Turret:- Tool Positions: 12- Tool Mounting Type: VDI-like- Turning Tool Shank Height: 25x25x150 mm- U-Drill Diameter: 20 mm- Boring Bar Shank Diameter: 40 mm- Indexing Time: Approx. 0.2 s (1 step)- Driven Tools (Live Tooling):- Drive Power (10 min rating): 5.5 kW- Speed Range: 25 - 4,500 rpm- Max. Torque: 35 Nm- Travel Ranges & Speeds:- X-Axis Travel: 230 mm- Z-Axis Travel: 575 mm- Rapid Traverse Rate X-Axis: 30 m/min- Rapid Traverse Rate Z-Axis: 33 m/min- Tool Setting / Monitoring:- Automatic Tool Breakage Recognition- Automatic Tool Wear Compensation Adjustment Range: 9,999 mm- Tool Presetter: Tool Eye- Coolant & Pneumatics:- Coolant Tank Capacity: 160 l- Pneumatic Pressure: 5 bar, 100 l/min- Machine Dimensions & Weight:- Connected Load: 46.2 kVA- Operating Voltage: 400 V / 50 Hz- Required Floor Space: 1.740 x 1.780 mm (Base layout space)- Transport Dimensions (QTN 200 M - U 500): 2,353 mm (L) x 1,780 mm (B) x 1,840 mm (H)- Machine Weight: Approx. 4,900 kg - 5,100 kgincluded: LNS QUICK LOAD SERVO 3 (2004)- Type: Automatic Short Bar Loader- Bar Diameter Range: 6 mm to 120 mm- Bar Length Range: 100 mm to 1600 mm

Technical Specification
Counter Spindle Yes
Gbjdjzqz D Nepfx Aa Usu
Driven Tools Yes
