Mazak QT 200MY

Excelent machine listed for sale!
Location: Pirot, Eastern Serbia.

Machine is in a perfect working condition. The machine comes with a lot of tools which can be seen in attached pictures.
Tool cabinet and worktable are included in the offer.

Contact us if you have any additional questons. You can contact us via Viber of Whatsapp.

Times:
Power on: 21398 h
Auto ope. :8183 h
Iedpfxow S Ex Uo Abxobc
Auto cut. : 6096 h
Total cut. : 4793 h
Total time: 21398 h
Technical data:

Control: Mazatrol Smooth G

Work-capacity
Max. swing diameter:695 mm
Max. machining diameter:380 mm
Max. machining length:555 mm
Max. bar material diameter:65 mm

Main-spindle
Spindle speed:35-5.000 RPM
Main spindle motor:26 kW
Max. torque:465 Nm
Spindle bore:76 mm
Spindle indexing increments:0° - 360°/0,0001 °

Turret
Turret tool capacity:12

Rotary tools
Spindle speed:25-5.000 RPM
Power:5,5 kW
Max. torque:47 Nm

Travel
X-axis stroke:234 mm
Y-axis stroke:100 (+/- 50) mm
Z-axis stroke:625 mm

Feedrate
Rapid traverse rate:
X-axis30 m/min
Y-axis21 m/min
Z-axis33 m/min
C-axis555 RPM

Cutting feed rate
X/Y/Z-axis0-2.000 mm/min

Machine-data
Electrical power supply:42,6 KVA
Machine weight 5.600 kg
Machine size (L x B x H), approx.2,80 x 1,90 x 2,00 m
