مازاك MAZAK VCN-530C

Mazak MAZAK VCN-530C

This 4-axis Mazak VCN-530C was manufactured in 2020. It features an impressive X-axis travel of 1,050 mm, Y-axis travel of 530 mm, and Z-axis travel of 510 mm. The machine includes a robust table size of 1,300 x 550 mm and a maximum table load of 1,200 kg. If you are looking to get high-quality machining capabilities, consider the Mazak VCN-530C vertical machining centre we have for sale. Contact us for further details.

Working area and travels
• Table-to-spindle nose: 150–660 mm
• Column surface to spindle centre: 586 mmTable
• Dimensions: 1,300 × 550 mm
• T-slots: 5 × 18 mm; pitch 100 mmSpindle
• Drive: Electrically selected two-range
• Spindle bearing bore: 70 mm
• Acceleration time: 2.0 s
• Motor power: 18.5 kW (5 min) / 11 kW (40% ED) / 7.5 kW (S1)Feed rates
• Rapid traverse X/Y/Z: 42 m/min
• Cutting feed X/Y/Z: 1–42,000 mm/minAutomatic tool changer
• Max tool diameter: 80 mm (adjacent tools) / 125 mm (adjacent pockets empty)
• Max tool length: 350 mm (from gauge line)
• Tool selection: MAZATROL random memory, shortest-path
• Tool-to-tool time: 1.3 sCoolant and chip management
• Through-spindle high-pressure coolant: approx. 15 kgf/cm² (~14.7 bar)
• Coolant tank: 250 L
• Coolant flushing for covers
• Manual washdown gun
Bwjdjz Iqy Eopfx Adkou
• Workpiece air blast
• Preparation for mist extractionControl functions and probing preparation
• Synchronous tapping
• Maximum program size: 8 MB
• G00 Slope Constant (rapid movement optimisation)
• Preparation for Renishaw OMP60 workpiece probeMachine dimensions
• Floor space: 2,880 × 3,102 mm

Additional equipment

• Kitagawa NC rotary table, MR250 series (Type: MR250RAE13)
• Date of manufacture: Oct 2020
• Weight: 85 kg
• Mechanical mounting for MR250 included
• CROWTHER left-side hinged-belt chip conveyor
• Additional working-area lighting
• Three-colour LED signal tower
• Polish manuals and safety labels

Technical Specification
Taper Size SK 40
