مركز التصنيع الأفقي

MAKA MK 7s

For sale is a high-precision 5/6-axis CNC machining center, MAKA MK 7s, from MAKA Systems GmbH, equipped with Siemens SINUMERIK 840D SL control and OP15 PCU operating unit.

The machine comes directly from production, is powered up, and can be inspected or demonstrated in operation at any time. It is in very well-maintained technical condition and has been serviced regularly.

TECHNICAL HIGHLIGHTS:
- 5-axis milling technology with retrofitted 6th axis (B-axis / Lehmann rotoFIX EA-530)
- Spindle completely overhauled (2025, €18,000 investment)
- Tool magazine with 20 positions (rotary table)
- Tool holder: HSK A63, max. speed 24,000 rpm, output 16 kW
- Rapid traverse: X/Y = 60 m/min, Z = 45 m/min
- Positioning accuracy per axis: ± 0.1 mm/m, repeat accuracy: ± 0.05 mm/m
- 3D wireless measuring probe, tool breakage detection, spray cooling unit
- Rectangular frame table with zero-point clamping system and chip management (brushes, guide plates, conveyor belt)
Redex Hv I Djpfx Ac Hobt
- Pneumatic/hydraulic workpiece clamping incl. hydraulic unit
- Hydraulic system up to 210 bar (3 clamping circuits)
- CAD data, technical documentation, and layout plan available

WORKING RANGE & DIMENSIONS:
- Travel (X/Y/Z): 2,900 / 1,900 / 1,000 mm
- A-axis: 196° C-axis: 540°
- B-axis (Lehmann rotary table): retrofitted, integrated with the control system
- Working area: 2,000 × 1,000 × 600 mm
- Machine weight: approx. 8 t
- Dimensions (L × W × H): approx. 6.7 × 3.0 × 3.7 m

FURTHER EQUIPMENT:
- Saw blade pick-up station (Ø 450 mm)
- Reinforced front doors, sheet metal safety enclosure with noise-reducing roof
- Automatic safety sliding doors
- Blowing nozzle in tool magazine (spindle cleaning)
- Electrical connection: 400 V / 50 Hz – 19 kW – 43 A
- Pneumatic connection: 6 bar / ½″ – air consumption approx. 800 l/h

OPERATING HOURS / RUN TIMES:
- Main power-on hours approx. 12,805 h (as of Oct 2025)
The meter runs whenever the machine is powered—during setup, maintenance, or idle time as well.
- Spindle run time: 4,314 h total
The current spindle was fully renewed and overhauled in 2025

SPECIAL FEATURES:
- Powered up – demonstration available at any time
- Direct from production – not a dealer sale
- Complete technical documentation available
- Support with dismantling, loading, and transport available (for a fee)

Price: €174,900 net – optionally incl. 6th axis (Lehmann) €199,000
Price is net, negotiable with quick turnaround.

All details have been provided to the best of our knowledge and belief. Subject to change, error, and prior sale.
