GMC MACCHINE SRL KGS 660S

VERTICAL PANEL SAW WITH ELECTRIC MOVEMENTS & DIGITAL DISPLAYS FOR CUTS
Brand: GMC MACCHINE SRL
Model Type: KGS 660S Serial No.: 13189 Year: 1998
(Photos taken prior to any potential refurbishment, machine offered as-is)
MACHINING CAPACITIES:
- Max. horizontal cutting length: 5300 mm
- Max. horizontal cutting height: 2100 mm
- Max. vertical cutting height: 2200 mm
- Max. cutting depth: 80 mm
OTHER FEATURES:
- Power supply: 380V Three-phase+T
Bsdpfxju R Ulhs Aflsdk
- Installed power: 7.5 kW
- Main motor power: 4.4 kW (6 hp)
- Saw blade speed: 5,200 rpm
Pneumatic blade feed
- Carbide-tipped saw blade: Ø 300 mm, bore Ø 30 mm
- Welded steel frame, PVC slat frame with automatic retraction via pneumatic cylinders
- Fully lengthwise pneumatic retractable intermediate support with 2 adjustable and retractable stops
- Retractable rollers for panel handling
- Pneumatic locking of the saw carriage
- 8 bar pneumatic feed
- Digital display for cuts
- Complete extraction system DPS
Back cover spans the entire rear of the machine
Lower longitudinal channel for sawdust collection
Multiple extraction points in the lower section
Extraction port: Ø100 mm
- Support for floor-mounted installation
- CE Marked
Total space required when mounted on supports: 6300 x 1600 x 3040 mm
(includes operator and maintenance area)
Transport dimensions, 2 packages:
. 1 frame 6300 x 860 x h.2620 mm
. 1 pallet 3150 x 1000 x 1000 mm
Total weight: 1250 kg
Please contact us for supply of consumables, accessories, and/or extraction systems.

Offered as a lot, without refurbishment or warranty.

Ex works price, excluding VAT.
Transport and services on request.
