آلة تسمير سطح السفينة

Foudila Oy DNM1600

Oy Foudila Ab is a company, in Kaskinen, Finland with over 45 years of experience in equipment for timber handling. For the past 15 years, we have also been active in pallet industry and have developed a lot of machines over the years for nailing, automatic timber feeding and stacking. We manufacture both standard machines and customized solutions for the customer's purposes.

DNM1600 is a flexible, compact and efficient pneumatic nailing machine for manufacturing deck for pallet industry. User-friendly program, which means that the changeover takes place very quickly and the machine can save settings for over 100 different decks. Bostitch nail guns that are equipped with nail magazines for jumbo coils with indicators. Opportunities for manufacturing asymmetrical decks. Equipped with flexible cassettes for boards. Protective cover for sound attenuation and for a safe function. The machine is controlled from a 10" touch screen. Beckhoff control system.


Dimensions for standard machine:

- Deck board: Length 600-1600mm, Width 75-125mm, Height 16-28mm

- Stringer: Length 600-1500mm, Width 50-125mm, Height 16-28mm

- Deck/Stringer pallet size: Length 600-1600mm, Width 600-1500mm

2-way pallet kit available as an extra option that makes it possible to produce stringer pallets/2-way pallets with a max. stringer height of 100mm.

Capacity:

- 3 Deck/min (With 5 deck boards)
Gsdpfoh Dpwcox Ab Isbk


Machine dimensions:

- Length 5000mm, Width 2500mm, Height 1900mm


The machines is CE-marked.


The machine can be equipped with automatic board feeding and deck/pallet stacking.


For more information, pictures or videos take contact.
