آلة اللكم والقضم

EUROMAC EUROMAC ZX 1000/30

gebraucht
2001
9647
prompt, Zwischenverkauf v
Italien
1
30 to
1250+N x 1000 mm
1250 mm
1000 mm
40 m/Min
30 m/Min
50 m/Min
30 mm
730 1/Min
300 1/Min
980 mm
4 kW
115 l
Chjdpfxewirkgs Ag Sjc
4000 mm
2780 mm
1900 mm
4000 x 2300 x 1900 mm + Z mm
4800 kg
With 6-way multitool holder MTE6 (max. Dm. 24 mm)
2 Clamping claws
Table with Brushes, table dimension 1970 x 2260 mm
Foot pedal
2 pcs. additional single matrix holders
PC with Euromac Software Eurowin 8.36
Max. Punching force 300 kN
Automatic repositioning up to 10.000 mm
Max. Punching diameter for single tool 88,9 mm,
Max. Punching diameter Multitool Holder MTE6 Dm. 24 mm
Max. Opening the clamping claws 7 mm
Transport width: 2350 mm
User Manual in english and italian
CE declaration available

WITH LARGE TOOL PACKAGE
several pieces of each of the following dimensions:
Round: Dm. 2,5/2,8/3/3,12/3,2/3,5/3,9/4,1/4/4,5/5/5,2/5,5/6/7/7,5/8/8,5/9/9 ,5/10/10,5/11/11,5/12/12,5/13/13,5/14/15/16/18/19/20/21/23
Square: 10/12/13/15 mm
Rectangle: 5x2/20x2/22x4 mm
Oblong hole: 10x6,5/12x8,5/12,2x10,7/18x5 mm
