مخرطة CNC

EMCO MAXXTURN 65Y

USED CNC LATHE EMCO MAXXTURN 65Y
- Serial N° : S6C123101
- Stock N° : 7539
- Year : 2012
- Number of production hours: 16 777 hours
MAIN SPINDLE
- Bar diameter: 65 mm
- Max swing over bed : 610 mm
- Max swing over slide : 360 mm
- Turning diameter: 500 mm
- Spindle nose: KK6
- Spindle speed : 5000 rpm
- C axis: 360° indexing increment 0.001°
SUB SPINDLE
- Spindle nose: KK6
- Spindle speed: 6000 rpm
- C axis: 360° indexing increment 0.001°
TURRET
- Number of positions: 12
- Number of motorized positions: 12
- Axis strokes : X=260mm - Y=+/-40 mm - Z1=610 - Z2=580 mm
- Rapid travers rates : X=30m/min - Y=15 m/min - Z=30 m/min

Equipped with :
- 1 CN SIEMENS
- 1 Chuck 3 jaws Ø 210 mm
Iodpfx Abex Iwa Dobsbf
- 1 Tool measuring arm
- 1 Part recovery arm
- 1 Tailstock for sub spindle
- 1 Collet holder Schaublin F68 on the main spindle
- 1 Collet holder Schaublin F48 on the sub spindle
- 4 Double frontal rotating tool holders
- 2 Single front rotating tool holders
- 3 Side rotating tool holders
- 7 Double fixed tool holders
- 108 Collets F68
- 1 Chip conveyor
