DMG MORI DMP 70

This 5-axis DMG MORI DMP 70 was manufactured in 2019. It features a maximum spindle speed of 24,000 rpm and a weight of 4,250 kg, making it a robust option for precision machining. If you are looking to get high-quality machining capabilities, consider the DMG MORI DMP 70 vertical machining centre we have for sale. Contact us for further details.

Hedpfxjzx Srye Af Tsfl
- Phase: L1/L2/L3/N/PE- Power Consumption: 30 kVA- Maximum Current (A In max): 43.5 A- Rated Current: 50 A- Short-Circuit Current (V max): 5 kA / 440 V max.- Voltage: 400 V ±10%- Frequency: 50 Hz- Control Voltage AC: 230 V- Control Voltage DC: 24 V- Control: 3D Control Siemens 840D SL Operate- Tool Taper: BBT30- Work Table: Integrated NC rotary tilt table, 5-axis simultaneous operation- Swivel Range A-Axis: -120° / +100°- C-Axis Operation: Continuous (Endless)- Maximum Load C-Axis: 100 kg- Table Diameter C-Axis: Ø290 mm- Drives: Torque drives including direct path measurement in A- and C-axis- Software Packages: Sinumerik MDynamics 5-Axis, 3D data model for simulation- Table Options: Clamping pneumatics (1-circuit)- Coolant & Chip Management: Chip conveyor, Production package belt filter with 40 bar internal coolant supply (IKZ), Blow air through spindle center, External blow air, Oil and emulsion mist separator system- Measuring & Monitoring: RENISHAW 3D touch probe kit, Tool breakage monitoring and in-machine measurement, Preparation for 3D quickSET- General Options: Operating mode 3, CE conformity- Automation Interface: Automation interface for external automation on the right- Automation System: DMG MORI WH 3 Cell- Robotic Arm: Fanuc LR Mate 200iD/7L yellow 6-axis robot- Robot Gripper: Double gripper PGN64- Automation Components: 10 DMG drawers, NIO chute, Alignment station, Measuring drawer, Raw material inlay system, Gripper set, Accessories- Machine Operating Hours (from control screen): Machine runtime: 22,918:34 h; Program runtime: 20,920:40 h; Spindle runtime: 18,815:51 h
