Bystronic BySprint Fiber 3015

This 3-axis Bystronic BySprint Fiber 3015 was manufactured in 2016, designed for precision fiber laser cutting. It handles a nominal sheet size of 3000 x 1500 mm and supports a maximum workpiece weight of 890 kg. The machine dimensions are 11,000 mm in length, 6,050 mm in width, and 2,565 mm in height. If you are looking to get high-quality cutting capabilities consider the Bystronic BySprint Fiber 3015 machine we have for sale. Contact us for more information.

• Nominal sheet size: 3000 x 1500 mm
• Cutting area (travel): X 3048 mm, Y 1524 mm, Z 70 mm
• Maximum positioning speed: Parallel (X,Y) 100 m/min; Simultaneous 140 m/min
• Accuracy: Positioning accuracy ±0.1 mm; Repeatability ±0.05 mm
• Maximum workpiece weight 890 kg
• Cut Control Fiber
• Detection Eye
• Automatic nozzle changer (40 positions)
• Parts and cross conveyors in the cutting area
• Dust extraction system with 200-liter drum adapter
