Breitner BFA 8003 آلة ترتيب الزجاجات (2022)

Breitner Flaschenaufsteller

Overview

This automatic bottle unscrambler was manufactured in 2022 by the German company Breitner Abfüllanlagen GmbH. The model BFA 8003 is a high-performance, fully automatic plastic bottle unscrambler designed for gentle handling and fast format changes with minimal change parts. It offers reliable operation even with challenging bottle geometries and lightweight PET containers.

The machine is a trade fair model, never used in production, and is therefore in as-new condition. It was only showcased at exhibitions and comes with a 12-month manufacturer warranty.

Technical data
Lhedjxqpk Dopfx Ad Noi

- Capacity: Up to 150 bottles/min
- Operation: Continuous from bulk hopper feed
- Bottle types: Plastic (PET, HDPE, etc.)
- Bottle dimensions: Ø up to 80 mm, length up to 100 mm, height up to 300 mm (larger possible upon request)
- Bottle orientation: Bottom-first via pneumatic flipping device
- Machine direction: Left to right
- Working height: 900 mm
- Frame: Welded, stainless steel (AISI 304)
- Sort drum diameter: 1,500 mm
- Control system: B&R industrial computer with 12.5” touchscreen, integrated diagnostics, remote access
- Electrical supply: 3 × 400 V, N, PE, 4 kW
- Compressed air: 400 Nl/min at 6 bar
- Machine guarding: Polycarbonate panels
- Safety: Error detection with clear text display
- Condition: As new (used for demonstration only)
- Warranty: 12 months manufacturer warranty
